Victron Phoenix Inverter 48V/1200VA/230V VE.Direct with Schuko Socket
SKU: PIN482121200
Victron Energy Inverter with pure sine wave output, high peak power and high efficiency. The combination of high-frequency and mains frequency technology offers optimal conditions.
VE.Direct communication port
The VE.Direct connector can be connected to the following devices:
With a computer (requires VE.Direct to USB interface cable)
With Apple and Android smartphones, tablets, Macbooks or other devices (requires VE.Direct Bluetooth Smart Dongle).
Fully configurable:
Thresholds for triggering and resetting low battery alarms.
Thresholds for switching off and restarting at low battery voltage values.
Dynamic shutdown: load-dependent shutdown threshold
Output voltage 210 - 245V
Frequency 50 Hz or 60 Hz
Threshold for ECO mode on/off and ECO mode sensor
Monitoring:
Input and output voltage and current alarm
- Manufacturer Victron Energy
- Commodity Code 85044083
- Dimensions (mm) (H x W x D) 190 x 440 x 290
Proven reliability
Complete bridging with an additional toroidal transformer topology has proven itself for years. The inverters are short-circuit-proof and protected against overheating (whether caused by overloading or the ambient temperature).
High inrush power
This is required to switch on loads such as voltage converters for LED lamps, halogen lamps or power tools.
Eco mode
In ECO mode, the inverter switches to standby as soon as the load falls below a preset value. In standby mode, the inverter then switches on for a short period (adjustable default setting: every 2.5 seconds). If the load exceeds a preset threshold value, the inverter remains switched on.
Remote on/off switch
A remote on/off switch can be connected to a two-pin connector or between the positive battery post and the left contact of the two-pin connector.
Load transfer to other AC sources: The automatic load transfer switch
For smaller outputs, we recommend the Filax automatic switch. Computers and other sensitive electronic devices can continue to be operated practically without interruption, since the switching times are very short (less than 20ms).
