GivEnergy High Voltage Battery Kit

SKU: GIV-BAT-KIT-HV

givenergy battery review

GivEnergy High Voltage Battery Kit

This high voltage stackable system is designed to work alongside the GivEnergy 3 phase hybrid inverters in larger residential systems, with monitoring and control via the GivEnergy portal and app to monitor state of charge, battery health and throughput. Modular design allows the system owner to increase the energy storage capacity as required between 10.2kWh and 20.4kWh with configurations of three, four, five or six 3.6kWh modules.

The LiFePO4 battery modules feature 100% depth of discharge and have a 0.5 C rating. Units are IP65-rated for outdoor installations and are backed by a 12-year manufacturer’s warranty.

Seen a better price?
Login to see Trade Prices
  • Manufacturer GivEnergy
  • Commodity Code 85049017
  • Dimensions (mm) (H x W x D) 545 x 445 x 230

Depending on the number of battery modules the dimensions of this product are (HxWxD):

3 battery modules, 10.2 kWh / 51 Ah: 635 x 380 x 480mm
4 battery modules, 13.6 kWh / 51Ah: 785 x 380 x 480mm
5 battery modules, 17.0 kWh / 51 Ah: 935 x 380 x 480mm
6 battery modules, 20.4 kWh / 51Ah: 1085 x 380 x 480mm
